Item No.: M-JB
Switchable Magnetic Jig Block
Switchable Magnetic Jig Block is assemblied with Neodymium magnet, powerful and smart in size
What is Switchable Magnetic Jig Block?
Dailymag Switchable Magnetic Jig Block is a powerful magenetic tool, designed for fixing iron plates, iron pipes, iron rods, angle steels, channel steels and other large iron pieces. It is assemblied with Neodymium magnet, powerful magnetic power and smart in size.
The bottom and all four sides of Magnetic Jig Block have magnetic fields, powerful to hold iron surface. The standard angle 90 degree fit most straight or vertical combination.
The Magnetic Jig Block have magnetic power switch design, a 180 degree Push-to-Rotate magnetic control switch, easy to power On and Off the magnetic strength. Easy to operate.
You can use Switchable Magnetic Jig Block to make a reliable magnetic fixer, or for welding fixation.
| Item No. | Dimension(mm) | Full Saturation Thickness | Shear Working Load | Net Weight | Maximum Pull Force | ||
| W | A | H | |||||
| M-JB6 | 50 | 31.5 | 66 | 4mm | 6kg | 0.38kg | 60kg(585N) |
| M-JB12 | 60 | 41.5 | 80 | 5mm | 8kg | 0.65kg | 120kg(1170N) |
M4x8mm threaded holes inside the jig can for attachment and fixtures.
